ISO 9001 Small Module Gear Shaft Reduction Gear Transmission Gear
A gear shaft refers to a mechanical part that supports a rotating part and rotates with it to transmit motion, torque, or bending moment. It is usually in the shape of a metal round rod, and each section can have different diameters. The parts that perform rotating motion in the machine are installed on the shaft.
Characteristics of gear shaft:
1. Compact structure: The gear shaft designs the gear and shaft as a whole, reducing the number of parts, making the structure more compact and conducive to saving space.
2. High transmission efficiency: The gear shaft directly transmits power from the gear to the shaft, reducing the energy loss during the transmission process, so the transmission efficiency is high.
3. Large transmission torque: The design of the gear shaft can withstand large torque and is suitable for the transmission of heavy-duty machinery.
4. Accurate positioning: The gears on the gear shaft usually have precise meshing requirements with other gears or transmission components, so the manufacturing accuracy of the gear shaft is high to ensure smooth transmission and accurate positioning.
The design of the gear shaft
Depending on the application scenarios, the gear shaft can be designed in different forms such as spur gears, helical gears, worm gears, etc. to meet different transmission requirements and installation conditions.
Gear shaft
| Products |
ISO 9001 Small Module Gear Shaft Reduction Gear Transmission Gear |
| Material |
Alloy steel, 42CrMo,42CrMn,35CrMn,45S |
| Shape |
Helical gear, Cylindrical gear |
| Manufacturing process |
Forging |
| Teeth Accuracy Grade |
ISO 5-8 Grade |
| Heat Treatment |
Normalizing & tempering |
| Application |
Reducer, ball mill, mine elevator, crusher |
DINGSCO-We are committed to being the best high-precision spiral bevel gears supplier.
1. 30 years experience in manufacturing industrial gears.
2. Main products: spiral bevel gears, high reduction ratios, hypoid gears and cylindrical gears.
3. In 2023, Hunan Dinghan New Material Technology Co., Ltd. was established as a specialized international export company business unit.
